Raven

Common FEATURES:

  • 22 (6110 Dunlop) jumbo frets.
  • 647,7mm scale (25,5″).
  • 400mm fretboard radius (15,75″).
  • Nut width: 43mm (1″11/16)
  • String spacing at bridge: W:10,8mm; F:10,6mm
  • Thin “F resin” fretboard to give a precise attack without dead notes (info).
  • Double way working truss-rod steel bar, allows favorite neck relief adjustment.
  • Hardened multi laminated neck, made up with 0,8mm. thick wood plies.
  • Asymmetrical (helicoidal) neck shape for comfortable playing .
  • Satin finish on body and satin finish on the neck or hi-gloss finish for the specified models.
  • Nickel plated Steel wound MANNE strings.
  • Tilted back headstock, one piece with the neck.
  • Natural or see-through color available.
  • MANNE pickups (info).
  • All wrenches and tools included with instruction notes on basic adjustment.

Raven

This new series is the result of the application of Manne’s ideas into a traditional and classic looking instruments.
The result is a quality update with a brand new modern features of playability and performance.

With our neck/body joint system, the shape of the body allow more upper frets accessibility with a sleek profile.

One of the feature that sports the Manne production is the neck/body jointer, a system that allow the neck to be installed very near the body edge without the need of a heel, giving a great access and a solid connection.

We applied this system with the result of a unique upper frets access. Manne quality neck provide fast and precise playability, commonly considered one of the best necks on the markets.

  • Korina Body
  • Wilkinson Traditional bridge 5+1
  • Wilkinson Tuners
  • Alnico V pick-ups (available also Manneblade minihumbuckers)
  • Reduced thickness resin fretboad neck, maple neck with laminate core
  • Asymmetrical neck shaping
  • Angled headstock
  • Direct bolt on body (no steel plate on back of body)
  • Multichambered body on the bodies with tops

Available with AlnicoV vintage pick-ups, or with our twin blade double sound minihumbucker controlled by 3 push/pull pots that give series/parallel connections.

Raven guitars are available in models Satin Special (satin with top), Satin (satin), Gloss Special (hi-gloss with top), Gloss (hi-gloss).
